KINGSTON 8GB DDR4 3200MHZ LAPTOP RAM Selectable BC4 or BL8 on-the-fly (OTF) Fly-by topology Terminated control command and address bus PCB: Height 1.18” (30.00mm) RoHS Compliant and Halogen-Free The Kingston Value RAM’s KVR32S22S8/8 is a 1G x 64-bit (8GB) DDR4-3200 CL22 SDRAM (Synchronous DRAM),1Rx8, non-ECC, memory module, based on eight 1G x 8-bit FBGA components. The SPD is programmed to JEDEC standard latency DDR4-3200 timing of 22-22-22 at 1.2V. This 260-pin DIMM uses gold contact fingers. Specifications: Model KVR32S22S8/8 Capacity 8GB Speed 3200Mhz Memory Type DDR4 Form Factor SODIMM Latency 22-22-22 Voltage 1.2V CL(IDD) 22 cycles Row Cycle Time (tRCmin) 45.75ns(min.) Refresh to Active/Refresh Command Time (tRFCmiin) 350ns(min.) Row Active Time (tRASmin) 32ns(min.) UL Rating 94 V – 0 Operating Temperature 0°C to 85°C Storage Temperature -55°C to 100°C Warranty Limited Lifetime
